GBP-PC Series Lithium Battery Cluster Energy Storage System

The GBP-PC Series is a high-voltage lithium battery cluster energy storage system developed for commercial and industrial applications. It is suitable for emergency power supply, peak shaving and valley filling, solar energy storage, UPS integration, and power supply in remote or weak-grid areas.

The system uses lithium iron phosphate cells and a customized BMS to manage battery operation safely and efficiently. Its modular battery rack structure helps reduce transportation volume, simplify installation and support flexible system configuration.

[email protected]

Consult Now

Product Features

Modular high-voltage battery cluster design.
Automatic ID recognition to save installation space and simplify commissioning.
One-button power on/off for convenient operation and maintenance.
Touch screen on each cluster for clear operating-status display.
Compatible with UPS systems, photovoltaic power generation systems and other main power equipment.
Supports CAN, RS485 and dry contact communication.
Detachable battery rack design helps reduce transportation space.

Technical Specifications

Item	Specification
Battery pack model	GBP51.2-314
Cell capacity	314 Ah
Nominal energy	16.1 kWh
Nominal voltage	51.2 VDC
Operating voltage range	48-56.8 VDC
Charging temperature	0-50 deg C
Discharging temperature	-10-65 deg C
Protection level	IP20
Reference weight	128 kg
Reference size	904 x 510 x 245 mm

Model	Nominal Voltage	Nominal Capacity	Operating Voltage Range	Recommended Current
GBP-PC2	102.4 V	314 Ah	96-113.6 V	150 A
GBP-PC3	153.6 V	314 Ah	144-170.4 V	150 A
GBP-PC4	204.8 V	314 Ah	192-227.2 V	150 A
GBP-PC5	256 V	314 Ah	240-284 V	150 A
GBP-PC6	307.2 V	314 Ah	288-340.8 V	150 A
GBP-PC7	358.4 V	314 Ah	336-397.6 V	150 A
GBP-PC8	409.6 V	314 Ah	384-454.4 V	150 A
GBP-PC9	460.8 V	314 Ah	432-511.2 V	150 A
GBP-PC10	512 V	314 Ah	480-568 V	150 A
GBP-PC11	563.2 V	314 Ah	528-624.8 V	150 A
GBP-PC12	614.4 V	314 Ah	576-681.6 V	150 A
GBP-PC13	665.6 V	314 Ah	624-738.4 V	150 A
GBP-PC14	716.8 V	314 Ah	672-795.2 V	150 A
GBP-PC15	768 V	314 Ah	720-852 V	150 A
GBP-PC16	819.2 V	314 Ah	768-908.8 V	150 A

Typical Applications

Commercial and industrial energy storage
Solar and wind energy storage systems
Peak shaving and valley filling
Emergency backup power
Remote areas, island power supply and weak-grid projects
Hybrid renewable energy systems

Project Selection Support

Send us your inverter brand, required DC voltage range, capacity target, installation environment and destination country. BESSENT can help recommend a suitable configuration and provide technical matching support.
