Customized according to specific customer requirements
1.No need for wind alignment, reducing gyroscopic forces when the rotor aligns with the wind, resulting in an aesthetically pleasing appearance and minimal operational vibration.
2.Can be equipped with assisting wind wheels to achieve start-up and power generation in light winds, maximizing the utilization of wind resources and increasing annual power generation, thus enhancing equipment's economic efficiency.
3.Equipped with multiple safety protections such as electromagnetic brakes, enabling automatic omnidirectional wind tracking, stronger typhoon resistance, and ensuring safe and reliable operation.
4.The wind turbine blades are precision-manufactured using advanced technology, combined with optimized aerodynamic shape and structural design, facilitating easy installation and achieving high wind energy utilization coefficient.
5.Utilizes professional magnetic circuit design, resulting in low motor startup torque, reduced startup wind speed, and increased wind energy utilization efficiency.
6.Offers rich customization options, supporting customization of blade colors and logos.
7.Suitable for applications in street lighting, road monitoring, scenic islands, and scenic area projects.
| Model | X3 | X5 | X7 | X9 | ||||
| Rated power | 200W | 300W | 500W | 600W | 800W | 1000W | 2000W | |
| Max. Power | 200W | 300W | 500W | 600W | 800W | 1000W | 2000W | |
| Rated wind speed | 11.5m/s | |||||||
| Rated voltage | 12V/24V | 48/96V/120V | 120V/220V | |||||
| Start-up wind speed | 2m/s | |||||||
| Wind wheel diameter | 0.53m | 0.62m | 0.8m | 0.9m | 1.67m | |||
| Blade height | 0.75m | 0.9m | 1.5m | 1.65m | 2.8m | |||
| Safety wind speed | 45m/s | |||||||
| Controller system | Electromagnetism | |||||||
| Generator | Three phase ac permanent magnet generator/Three phase maglev generator | |||||||
| Connection type | flange connection | |||||||
| Blade material | Reinforced Aluminium alloy | |||||||
| Working temperature | -40℃-70℃ | |||||||
| Design life | 25 Years | |||||||
| Cut in speed | ≤3.5m/s | |||||||
| Tower spec | 6m 9m or customized | |||||||
| Insolation grade | F | |||||||
| IP grade | IP54 | |||||||
