The characteristics of permanent magnet generators: Using rare earth permanent magnetic materials (such as neodymium iron boron), no excitation current is required. The structure is simpler. By adjusting the three-phase current, the stator magnetic field and the rotor magnetic field rotate synchronously, with an efficiency of up to 92%-96%. They are suitable for scenarios such as wind power generation and high-speed power generation in aviation, and are particularly suitable for fields with high efficiency requirements.
Product Features
The characteristics of permanent magnet generators: Using rare earth permanent magnetic materials (such as neodymium iron boron), no excitation current is required. The structure is simpler. By adjusting the three-phase current, the stator magnetic field and the rotor magnetic field rotate synchronously, with an efficiency of up to 92%-96%. They are suitable for scenarios such as wind power generation and high-speed power generation in aviation, and are particularly suitable for fields with high efficiency requirements.
Technical Specifications
型号 Model | G-3000 | G-5000 | G-10000 | ||
额定功率 Rated power | 3000w | 5000w | 10kw | ||
额定电压 Rated voltage | 120v/220v/240v/380v (可定制/Accept customization) | ||||
额定转速/频率 Rated speed/hz | 300rpm/50hz (可定制/Accept customization) | ||||
发电机直径 Generator diameter | 350mm | ||||
发电机长度 Generator length | 185mm | 305mm | |||
主轴直径 Shaft diameter | 50mm | ||||
主轴长度 Shaft length | 86mm | ||||
发电机类型 Generator type | 稀土永磁三相交流发电机/ Rare earth permanent magnet three -phase alternator | ||||
额定扭矩 Rated torque | 95.5 N*m | 160 N*m | 319 N*m | ||
极数 The number of |
poles | 20 | |||
转换效率 Conversion |
efficiency | ≥90% | |||
绝缘等级 Insulation class | F | ||||
磁钢材料 Magnetic steel material | 稀土钕铁硼/Rare earth neodymium NdFeB | ||||
工作温升 Temperature rises | ＜70℃ | ||||
工作温度 Operating temperature | -40℃ -120℃ | ||||
润滑方式 Lubrication method | 加注润滑脂/Grease is added | ||||
使用寿命 Service life | ≥25 years | ||||
型号 Model | G-15k | G-20k | G-30k | ||
额定功率 Rated power | 15kw | 20kw | 30kw | ||
额定电压 Rated voltage | 220v/240v/380v (可定制/Accept customization) | ||||
额定转速/频率 Rated speed/hz | 300rpm/50hz (可定制/Accept customization) | ||||
发电机直径 Generator diameter | 350mm | ||||
发电机长度 Generator length | 255mm | 465mm | 595mm | ||
主轴直径 Shaft diameter | 50mm | 60mm | |||
主轴长度 Shaft length | 86mm | 100mm | |||
发电机类型 Generator type | 稀土永磁三相交流发电机/ Rare earth permanent magnet three -phase alternator | ||||
额定扭矩 Rated torque | 477.5N*m | 637N*m | 955N*m | ||
极数 The number of |
poles | 20 | |||
转换效率 Conversion |
efficiency | ≥90% | |||
绝缘等级 Insulation class | F | ||||
磁钢材料 Magnetic steel material | 稀土钕铁硼/Rare earth neodymium NdFeB | ||||
工作温升 Temperature rises | ＜70℃ | ||||
工作温度 Operating temperature | -40℃ -120℃ | ||||
润滑方式 Lubrication method | 加注润滑脂/Grease is added | ||||
使用寿命 Service life | ≥25 years | ||||
型号 Model | G-50k | G-60k | G-100k | ||
额定功率 Rated power | 50kw | 60kw | 100kw | ||
额定电压 Rated voltage | 220v/240v/380v/480v (可定制/Accept customization) | ||||
额定转速/频率 Rated speed/hz | 167rpm/77rpm/100rpm/50hz (可定制/Accept customization) | ||||
发电机直径 Generator diameter | 550mm | 1075mm | 920mm | ||
发电机长度 Generator length | 1015mm | 1140mm | 830mm | ||
主轴直径 Shaft diameter | 85mm/100mm/120mm (可定制/Accept customization) | ||||
主轴长度 Shaft length | 150mm/180mm/200mm (可定制/Accept customization) | ||||
发电机类型 Generator type | 稀土永磁三相交流发电机/ Rare earth permanent magnet three -phase alternator | ||||
额定扭矩 Rated torque | 2860N*m | 7442N*m | 9550N*m | ||
极数 The number of |
poles | 36 | 78 | 60 | |
转换效率 Conversion |
efficiency | ≥90% | |||
绝缘等级 Insulation class | F | ||||
磁钢材料 Magnetic steel material | 稀土钕铁硼/Rare earth neodymium NdFeB | ||||
工作温升 Temperature rises | ＜70℃ | ||||
工作温度 Operating temperature | -40℃ -120℃ | ||||
润滑方式 Lubrication method | 加注润滑脂/Grease is added | ||||
使用寿命 Service life | ≥25 years | ||||
型号 Model | G-500k | ||
额定功率 Rated power | 500kw | ||
额定电压 Rated voltage | 380v/480v/600v (可定制/Accept customization) | ||
额定转速/频率 Rated speed/hz | 68rpm/50hz (可定制/Accept customization) | ||
发电机直径 Generator diameter | 1580mm+- | ||
发电机长度 Generator length | 1940mm+- | ||
主轴直径 Shaft diameter | 200mm (可定制/Accept customization) | ||
主轴长度 Shaft length | 300mm (可定制/Accept customization) | ||
发电机类型 Generator type | 稀土永磁三相交流发电机/ Rare earth permanent magnet three -phase alternator | ||
额定扭矩 Rated torque | 70220.6N*m | ||
极数 The number of |
poles | 88 | |
转换效率 Conversion |
efficiency | ≥90% | |
绝缘等级 Insulation class | F | ||
磁钢材料 Magnetic steel material | 稀土钕铁硼/Rare earth neodymium NdFeB | ||
工作温升 Temperature rises | ＜70℃ | ||
工作温度 Operating temperature | -40℃ -120℃ | ||
润滑方式 Lubrication method | 加注润滑脂/Grease is added | ||
使用寿命 Service life | ≥25 years | ||
