The characteristics of permanent magnet generators: Using rare earth permanent magnetic materials (such as neodymium iron boron), no excitation current is required. The structure is simpler. By adjusting the three-phase current, the stator magnetic field and the rotor magnetic field rotate synchronously, with an efficiency of up to 92%-96%. They are suitable for scenarios such as wind power generation and high-speed power generation in aviation, and are particularly suitable for fields with high efficiency requirements.
Product Features
The characteristics of permanent magnet generators: Using rare earth permanent magnetic materials (such as neodymium iron boron), no excitation current is required. The structure is simpler. By adjusting the three-phase current, the stator magnetic field and the rotor magnetic field rotate synchronously, with an efficiency of up to 92%-96%. They are suitable for scenarios such as wind power generation and high-speed power generation in aviation, and are particularly suitable for fields with high efficiency requirements.
Technical Specifications
型号 Model | L2 -2000 | L2 -2500 | L2 -3000 | ||
额定功率 Rated power | 2200w | 2700w | 3200w | ||
额定电压 Rated voltage | 48v/96v/120v/220v/240v/380v | ||||
额定转速/频率 Rated speed/hz | 333rpm/50hz (可定制/Accept customization) | ||||
发电机直径 Generator diameter | 235mm | ||||
发电机长度 Generator length | 225mm | ||||
主轴直径 Shaft diameter | 40mm | ||||
主轴长度 Shaft length | 65mm | ||||
发电机类型 Generator type | 稀土永磁三相交流发电机/ Rare earth permanent magnet three -phase alternator | ||||
额定扭矩 Rated torque | 57.36 N*m | 71.7 N*m | 87 N*m | ||
极数 The number of |
poles | 18 | |||
转换效率 Conversion |
efficiency | ≥90% | |||
绝缘等级 Insulation class | F | ||||
磁钢材料 Magnetic steel material | 稀土钕铁硼/Rare earth neodymium NdFeB | ||||
工作温升 Temperature rises | ＜70℃ | ||||
工作温度 Operating temperature | -40℃ -120℃ | ||||
润滑方式 Lubrication method | 加注润滑脂/Grease is added | ||||
使用寿命 Service life | ≥25 years | ||||
