The characteristics of permanent magnet generators: Using rare earth permanent magnetic materials (such as neodymium iron boron), no excitation current is required. The structure is simpler. By adjusting the three-phase current, the stator magnetic field and the rotor magnetic field rotate synchronously, with an efficiency of up to 92%-96%. They are suitable for scenarios such as wind power generation and high-speed power generation in aviation, and are particularly suitable for fields with high efficiency requirements.
Product Features
The characteristics of permanent magnet generators: Using rare earth permanent magnetic materials (such as neodymium iron boron), no excitation current is required. The structure is simpler. By adjusting the three-phase current, the stator magnetic field and the rotor magnetic field rotate synchronously, with an efficiency of up to 92%-96%. They are suitable for scenarios such as wind power generation and high-speed power generation in aviation, and are particularly suitable for fields with high efficiency requirements.
Technical Specifications
型号 Model | L -600 | L -800 | L -1000 | L -1500 | L -2000 | L -2500 | ||
额定功率 Rated power | 700w | 900w | 1100w | 1600w | 2200w | 2700w | ||
额定电压 Rated voltage | 24v/48v/96v | 48v/96v/120v/220v/240v/380v | ||||||
额定转速/频率 Rated speed/hz | 500rpm/50hz | |||||||
发电机直径 Generator diameter | 190mm | |||||||
发电机长度 Generator length | 126mm | 136mm | 197mm | |||||
主轴直径 Shaft diameter | 30mm | 35mm | ||||||
主轴长度 Shaft length | 50mm | 60mm | ||||||
发电机类型 Generator type | 稀土永磁三相交流发电机/ Rare earth permanent magnet three -phase alternator | |||||||
额定扭矩 Rated torque | 11.46N*m | 15.28N*m | 19.1N*m | 28.65N*m | 38.2N*m | 47.75N*m | ||
极数 The number of |
poles | 12 | ||||||
转换效率 Conversion |
efficiency | ≥90% | ||||||
绝缘等级 Insulation class | F | |||||||
磁钢材料 Magnetic steel material | 稀土钕铁硼/Rare earth neodymium NdFeB | |||||||
工作温升 Temperature rises | ＜70℃ | |||||||
工作温度 Operating temperature | -40℃ -120℃ | |||||||
润滑方式 Lubrication method | 加注润滑脂/Grease is added | |||||||
使用寿命 Service life | ≥25 years | |||||||
